Closing
Automatically via inbuilt adjustable timer.
Color sheet pile
RAL 1003 – Signal Yellow. Other colours can be available upon request.
Frame
Heavy duty galvanised steel fabricated legs (Thermaspeed) with dual function, door mass support and conditioned air plenum (Thermaster).
Operation
Microprocessor based frequency converter with low voltage controls. 3-way push-button station (OPEN ~ E-STOP ~ CLOSE).
R-value panels
Approximately 8.05 m2K/W (Thermaster), Approximately 0.16 m2K/W (Thermaspeed)
Curtain Specifications
900 gsm PVC coated woven polyester.
Temperature Resistance
DIN 53372 -36ºC to +80ºC.
Low Flammability
DIN 75200 <100 mm/min.
Curtain Features
CFC free, UV resistant with integrated wind bars to ensure curtain integrity. Anti-wear pads on wind bar ends.
Supply
230 V, single phase, 50 Hz, 16 A (Thermaspeed) or 32 A (Class C MCB) (Thermaster).
Thermair Generator
Integrated unit providing a low temperature conditioned air flow (Thermaster).
Extendibility
Prepared to accept a multitude of inputs from induction loop detectors, motion detectors, pull-cords, push-buttons, etc.
Opening Speed
Up to 2.0 m/s, depending on size.
Closing Speed
Up to 2.0 m/s, depending on size.
Leaf Format
Single curtain vertical rapid roll (Thermaspeed). Twin curtain vertical rapid roll with, 'Thermair', barrier.
Frame Finish
Standard PPC RAL 3020 - Traffic Red. Other standard RAL colours and stainless steel are available.
Canopy
The door is fitted with a full width roller canopy and an integrated motor cover with finish to match the support frame.
Additional options
Motor cover available as an option in a finish to match the support frame (Thermaspeed).
