Closing
Handle with multi-point closure.
Seal
Double sealing by means of rubber profiles.
Color PVC
Similar to RAL 9010 (white)
Emergency unlock
On the inside (only with windowed escape hatch).
Frame
Contra window frame for building into max. 100 and 200mm.
Locking
By means of a cylinder lock in the handle (control window) or padlock provision (windowed escape hatch).
R-value panels
Approx. 0,88 (m².K/W)
Dimensions
Control window 580x810mm (wxh) for building into ceiling, door leaf or panel wall. Windowed escape hatch 710x810mm (wxh) for building into door leaf or panel wall.
Direction of rotation
Right opening (seen from outside)
Construction
Synthetic hinged window and frame manufactured from impact-resistant PVC.
Glazing
Gas filled HR ++ insulation glass. Insulation glass according to NEN 2608. Control window constructed from single-layered safety glass 3-3-1.
