CA door with inflatable sealing

KHG-1810 - 100mm

Door leaf constructed of a core of 100mm insulation material, covered on both sides with polyester and finished all round with anodized aluminium profiles, thermal bridge-free. Equipped with an aluminium drop/lift rail system.

  • 100% gas-tight due to inflatable sealing.
  • Even in case of any irregularities in floor and wall after years still 100% tight.
  • No vaseline or sealant required for sealing.
  • It takes only seconds to open and reseal Salco CA doors.
  • Seamless door leaf.
  • Door leaf and frame fully thermal bridge-free.
  • Light in weight due to the use of high quality polyester (available in various colours).
  • Deliverable as self-assembly pack.
  • Various designs: horizontal, vertical and hinged doors.
  • 40 years worldwide experience.
Border
Anodized aluminium profiles, thermal bridge-free.
Closing
Not included. Available at additonal price.
Seal
100% gas-tight by means of inflatable profiles.
Door leaf color
Atandard colour RAL 9016 (white). RAL 6010 (green), RAL 5005 (blue) or RAL 7016 (anthracite).
Color PVC
Eloxierte Aluminiumrahmenprofile mit vollständigem kältebrückenfreiem Wandanschluss.
Frame
Anodized aluminium profiles with a complete thermal bridge-free fit to the wall.
Operation
Manually operated (horizontal), chain operated (vertical). Electrical operation at additional price.
Rail system
Anodized aluminium drop/lift rail system type SRA with dust cap (horizontal), galvanized and powder coated guiding system (vertical).
R-value panels
Approx. 3,7 (m².K/W).
Construction
Door leaf constructed of a core of insulation material, covered on both sides with 1,5mm impact resistant glass-fibre reinforced foodsafe polyester.
Thickness door leaf
100 mm.
Additional options
Bumper, threshold, finish of the clear opening, CA window, rain cap and more.
